Scalable mGig Ethernet Controllers

Client Computing at its Best

Marvell Scalable mGig Ethernet Controllers

Scalable mGig Ethernet Controllers

Marvell Scalable mGig Ethernet controller solutions for motherboards, PCs, Workstations, docking station, NAS, Router, Gateways and other embedded applications.

Marvell Scalable Gig controllers incorporate industry-proven Alaska® mGig  PHY technology which enables the delivery of Multi-Gig Ethernet over copper cabling. All Marvell Scalable mGig controllers are compliant to the IEEE 802.3bz standard and are backward-compatible with legacy 1000BASE-T Ethernet.

Key Features

  • Integrated PCIe, MAC, and PHY solution enables power and space-efficient connectivity for client systems
  • PCIe Gen4, Gen3 and Gen2 interface with x1/x2/x4 lane-widths delivering maximum flexibility
  • IEEE® 802.3bz and NBASE-T compliant AQrate PHY supporting 10GBASE-T/5GBASE-T/2.5GBASE-T/1000BASE-T/ 100BASE-T/ 10BaseT
  • MSI, MSI-X, LSO, RSS, and IPv4/IPv6 Checksum offloads for high performance and low CPU utilization
  • Energy Efficient Ethernet, Wake On LAN, and power management features
  • Jumbo frame support (up to 16Kbytes)
  • Driver support: Windows 10 and Windows 11 (64-bit), Linux 3.10 and higher
  • Remote boot: UEFI and PXE



Product Comparison Chart

PRODUCT NAME DESCRIPTION Speed DOCUMENTATION
AQC113 Single-port 6 speed, 12mm x 14mm, 10Gbps PCIe Gen4 x4 to Multi-Gig Ethernet controller with Industrial temperature support 10G Product Brief
AQC114 Single-port 5 speed, 12mm x 14mm, 5Gbps PCIe Gen3 x2 to Multi-Gig Ethernet controller with Industrial temperature support 5G Product Brief
AQC114CS Single-port 5 speed, 7mm x 7mm, 5Gbps PCIe Gen3 x1 to Multi-Gig Ethernet controller with Industrial temperature support 5G Product Brief
AQC115C Single-port 4 speed, 7mm x 7mm, 2.5Gbps PCIe Gen2 x1 to Multi-Gig Ethernet controller with Industrial temperature support 2.5G Product Brief

Documentation

Additional Information

Additional product information is available under NDA on the Marvell Extranets. To contact Marvell Sales, please submit your inquiry via request for information below.

REQUEST FOR INFORMATION
