NITROX® III Security Processor Family
- The industry's highest performance cryptographic acceleration with the latest security algorithms
- Industry leading GZIP & LZS compression
- Virtualization support
To provide an ideal platform for the next-generation of security applications.
NITROX III products are software compatible with the Cavium NITROX PX and NITROX Lite family of security processors. Cavium provides a comprehensive Software Development Kit that includes C-source code for Linux and FreeBSD drivers. The SDK also includes APIs for OpenSSL, OpenSSH, IPsec, Zlib, key management, test utilities and reference code for easy portability
NITROX III processors are highly scaleable and deliver performance ranging from 5 Gbps to 32 Gbps for full IPsec protocol or SSL offload, 1024bit exponent RSA from 35K to 230K RSA operations per second, and 2048bit exponent RSA up to 41K RSA operations per second enabling an optimal solution for applications such as:
- Application Delivery Controller (ADC)
- WAN Optimization
- Cloud Computing
- Server Offload - Web, Mail, Search
- Integrated VPN/Firewall appliances
- UTM Gateway, Routers
- Load Balancers/L4+ Switches
- Wireless LAN and WAN equipment
- Security Telco gateways
- SAN appliances
- 3G & 4G/LTE infrastructure equipment
For applications requiring 2.5 Gbps or below see our software compatible NITROX PX family.
| DEVICE | DATA INTERFACE | LOCAL MEMORY FOR SA OR CONTEXT | MAX RSA 1024-BIT EXPONENT | RSA 2048BIT EXPONENT | INLINE FULL IPSEC PROCESSING THROUGHPUT MBPS (W/AES+SHA2) |
FULL SSL RECORD THROUGHPUT MBPS | COMPRESSION |
|---|---|---|---|---|---|---|---|
| NITROX III PCI-Express CNN35XX - PCIe Look-aside Processor - Crypto, Compression & Virtualization | |||||||
| CNN3510 –C5 | PCI-E Gen 2 x4, x8, x16 | No | 35K | 6K | 5 Gbps | 5Gbps | 5Gbps |
| CNN3530 –C10 | PCI-E Gen 2 x4, x8, x16 | No | 75K | 13K | 10 Gbps | 10 Gbps | 10 Gbps |
| CNN3550 –C20 | PCI-E Gen 2 x4, x8, x16 | No | 150K | 26K | 20 Gbps | 20 Gbps | 20 Gbps |
| CNN3550-C20 (Boost) |
PCI-E Gen 2 x4, x8, x16 | No | 200K | 35K | 28 Gbps | 28 Gbps | 20 Gbps |
| CNN3560-C20 | PCI-E Gen 2 x4, x8, x16 | No | 230K | 41K | 32 Gbps | 32 Gbps | 25 Gbps |
| Note: Standalone Security and Compression options are available for some SKUs | |||||||
Documentation
Additional Information
Additional product information is available under NDA on the Marvell Extranets. To contact Marvell Sales, please submit your inquiry via request for information below.
