Automotive Ethernet PHYs, Switches and Bridges

Building end-to-end Ethernet in-vehicle networks

Marvell Automotive Ethernet PHYs, Switches and Bridges

Ethernet PHYs, switches and bridges for in-vehicle networks

The Brightlane™ Automotive Ethernet portfolio of PHY transceivers, switches and bridges supports networks speeds from 100 Mbps to 10 Gbps and the security and safety  features required for today’s and tomorrow’s in-vehicle networks.

Explore Automotive Networking

Brightlane Automotive Ethernet PHYs

Modern vehicles are becoming data centers on wheels. Advanced emerging features such as collision detection, lane departure warnings, and autonomous driving require massive amounts of secure data processing, networking and storage.



Brightlane Ethernet PHYs

Marvell's Automotive Ethernet PHY family of solutions support 10GBASE-T1, 5GBASE-T1, 2.5GBASE-T1, 1000BASE-T1, 100BASE-T1, 1000BASE-T, 100BASE-TX, and 10BASE-T standards. 2.5G/5G/10GBASE-T1 single pair Ethernet PHY implement the Ethernet physical layer as defined by IEEE 802.3ch standard. 100/1000Base-T1 single pair Ethernet PHY implement the Ethernet physical layer as defined by the IEEE 802.3bw and IEEE 802.3bp standard. These are ideally suited for a wide range of automotive applications, they are manufactured using a standard digital CMOS process and contain all the active circuitry required to implement the physical layer functions to transmit and receive data on a single balanced twisted pair.

Automotive Ethernet PHY integrates media dependent interface (MDI) termination resistors into the PHY which simplifies the board layout and reduces board cost by reducing the number of external components. Also, they support an integrated voltage regulator to generate all required voltages so the device can run off a single 3.3V supply.

  • 2.5G/5G/10GBASE-T1, IEEE 802.3ch-compliant
  • 1000BASE-T1, IEEE 802.3bp-compliant
  • 100BASE-T1, IEEE 802.3bw-compliant
  • RGMII / SGMII to Copper
  • Supports OPEN Alliance TC10
  • Supports IEEE 802.1AE MACsec
  • Supports 802.1AS – precision time protocol (PTP)
  • MDC/MDIO management interface eliminate passive components
  • Integrated voltage regulations
  • AEC-Q100 Automotive Standard compliant

2.5G/5G/10GBASE-T1 Automotive Ethernet PHY with integrated MACsec and compliant with IEEE 802.3ch (P/N: 88Q4364)

100/1000BASE-T1 Automotive Ethernet PHY with integrated MACsec and compliant with OPEN Alliance TC10, IEEE 802.3bp and IEEE 802.3bw (P/N: 88Q222xM)

Dual 1000BT1 Automotive Ethernet PHY with integrated MACsec and compliant with OPEN Alliance TC10 and IEEE 802.3bp (P/N: 88Q2233M)

100/1000BASE-T1 Automotive Ethernet PHY compliant with IEEE 802.3bp and IEEE 802.3bw (P/N: 88Q211x)

100BT1 Automotive Ethernet PHY with integrated MACsec and compliant with OPEN Alliance TC10 and IEEE 802.3bw (P/N: 88Q120xM)

100BASE-T1 Automotive Ethernet PHY compliant with OPEN Alliance TC10 and 802.3bw (P/N: 88Q111x)

100BASE-T1 Automotive Ethernet PHY, Single Port, MII/RMII/RGMII to Copper Transceiver (P/N: 88Q1010)

10/100/1000BASE-T PHY, Single Port, EEE, RGMII/SGMII to Copper/Fiber/SGMII Transceiver (P/N: 88EA1512)

10BASE-T/100BASE-TX automotive qualified Ethernet PHY layer (P/N: 88EA1517)

Brightlane Ethernet Switches

Marvell’s automotive ethernet switch family of products offer advanced features designed for today’s in-vehicle networks. With advanced security, like Trusted Boot and deep packet inspection, and Time Sensitive Networking features, these switches are ideal for automotive applications such as advanced driver assistance systems, central gateways, body domain controllers, and in-vehicle infotainment.

  • Advanced automotive security features, including deep packet inspection (DPI) and Trusted Boot functionality
  • Low power consumption
  • Support the latest IEEE 802.1 Audio Video Bridging (AVB) and Time Sensitive Networking (TSN) standards
  • Flexible port configurations ranging from 5-11 ports with integrated 100BASE-T1 PHYs and multi-gigabit Ethernet SerDes interfaces

Brightlane Q6223

12-port Automotive Ethernet central switch with integrated 1000BASE-T1 PHYs and MACsec (P/N: MV-Q6223)

Brightlane Q6222

9-port Automotive Ethernet central switch with integrated 1000BASE-T1 PHYs and MACsec (P/N: MV-Q6222)

16-Port Automotive Ethernet Switch with Integrated 1000BASE-T1 PHYs and MACsec (P/N: 88Q5192)

9-Port Automotive Ethernet Switch with Integrated 1000BASE-T1 PHYs and MACsec (P/N: 88Q5152)

11-port secure automotive Ethernet switch with integrated 100BASE-T1 PHY (P/N: 88Q5072)

11-port automotive Ethernet switch with Advanced Security and Support for TSN (P/N: 88Q6113)

8-Port Ethernet gigabit capacity switch with 4 fixed 100BASE-T1 ports, and a configurable selection of an additional 4 ports from 1 100BASE-T1, 1 100BASE-TX, 2 MII/RMII/RGMII, 1 GMII, and 1 SGMII port (P/N: 88Q5050)

5-port Ethernet switch offers 3x IEEE 100BASE-T1 ports, 1x IEEE 100BASE-T1 port, 2x MII/ RMII/RGMII or GMII port, and 1x Serdes or SGMII port (P/N: 88Q5030)

7-Port AVB GE Switch, 2 10/100/1000BASE-T PHYs + 3 RGMII/MII/RMII + 2 Serdes/SGMII (P/N: 88EA6321)

7-Port AVB GE Switch, 5 10/100/1000BASE-T PHYs + 2 RGMII/MII/RMII + 1 Serdes/SGMII (P/N: 88EA6352)

Brightlane Ethernet Bridge


The Brightlane QB5224 device is a multi-gigabit Ethernet bridge designed for automotive applications. The device is designed to directly connect to automotive-grade cameras, graphics processing units (GPUs), etc, via CSI-2 interface as defined by the MIPI Alliance. The bridge implements the Ethernet physical layer portion of the 10GBASE-T1 standard as defined by the IEEE 802.3ch task force.



  • 4 lanes of MIPI CSI-2 Rx/Tx
  • 10GBASE-T1, IEEE 802.3ch-compliant
  • I2C Support
  • AEC-Q100 Grade 2 (-40°C to +105°C)

4 lane CSI-2 Controller to 10GBASE-T1 Automotive Ethernet Bridge with integrated MACsec (P/N: 88QB5224)
